P1.25

TechnicalParameterSmallPixelLEDDisplay Pl.25/ Pl.56/ Pl.667/ Pl.875/ Pl.904/ Pl.923/ P2

Brand Name

T.I LED COMPANY

Place of Original

Guangzhou City, Guangdong Province, China

Model

P1.25

After-Sales Service and Warranty:

T.I has a professional and efficient after-sales service team, whose members have rich industry experience and technical knowledge, and can provide customers with timely and accurate technical support and solutions.

Personalized pre-sales and after-sales support

We Keep Buyer Information Completely Confidential!

INQUIRY NOW

Detail

Technical Parameter
Small Pixel LED Display	Pl.25	Pl.56	Pl.667	Pl.875	Pl.904	Pl.923	P2
Mod ule size(mm)	200*150	200*150	200*150	240*240	160*160	200* 150	256*128
Module resolution(pixel)	160*120	128*96	120*90	128*64	84*84	104*78	64*64
Pixel density(dots/m2)	640,000	409,600	360,000	284,444	275,625	270,400	250,000
Scan	1/30S	1/32S	l /30S	1/32S	1/28S	1/26S	1/32S
Pixel configuration	SMD1010	SMD1010	SMD1010	SMD1515	SMD1515	SMD l 515	SMDl 515
LED lamp	Nat1onstar
IC	6153/6124
Refresh(HZ/s)	3840	3840	3840	3840	3840	3840	3840
brightness (cd/m2)	1000	1000	1000	1000	1000	1000	1000
Best view distance	2-5m	2-5m	2-5m	2-5m	2-5m	2-5m	2- l Om
Cabinet size(mm)	400*300	400*300	400*300	480*480	480*480	400*300	512*512
Cabinet material	Die casting aluminum

Viewing angle	140^。W，· 140 ^。H
IP grade	IP43
Life span	I 00,000 hours
Working Voltage	AC 220 V/ 110 V± l 0%
Defect Rate	<0.0001
Maintenance mod e	front I back
Average power consumption	300 W/m2
Max power consumption	600 W/m2
Operating Temperature	30^。C ＋60^。C ; 10% 95%RH
Control system	Novastar/Colorlight/Huidu/Linsn/Sheen Color
Signal Input	HDMI, DVI, VGA, RF，S-Video, RGB, RGBHV , YUV, YC&Composition, etc.
Control Distance	120 m (no repeating) ; Optical fiber transmission: 500m- !Okm
Systems Operating Platform	WINDOWS(WIN2000 / WINXP/ WIN7/ WINS/ WIN I O)
